Ritter 28kW Thermal High Temp Heat Pump 3 Phase
Ritter thermal is an inverter air to water heat pump with R290 refrigerant and high efficency, optimized for underfloor, radiator & hot water applications.
Out of stock, available to backorder
LEADING THE WAY WITH R290 TECHNOLOGY
Waterware stock the most extensive range of R290 high temperature heat pumps in New Zealand. R290 is refrigerant grade propane with a Global Warming Potential (GWP) = 3 and is recognised to have the most developed potential in the industry. R290 multi-pass heat pumps provide highly flexible performance for all types of commercial space heating, cooling, and highcapacity domestic hot water applications, and combining this with Waterware’s commitment to reducing carbon emissions we’re proud to be part of the solution.
A WINNING FORMULA
The key to unlocking R290’s full potential lies in expertise. Since bringing the very first R290 hydronic monobloc heat pump to the New Zealand market in 2019, Waterware has developed unrivalled experience in R290 appliances and advanced control systems. For example, our own Messana MBOX BMS system which can seamlessly integrate heat pumps with traditional boilers in a hybrid configuration, ensuring reliable performance and manageable electrical loading, while maximizing efficiency and minimizing reliance on fossil fuels.
Heating Capacity Range (kW): 7.61-27.94
Max Power Input (kW): 12.6
Max Current Input (Amps): 17a per phase
Max Output Temp: 70ºC
COP 35-30ºC @ 7ºC: 4.69
COP 55-50ºC @ 7ºC: 2.85
COP 35-30ºC @ 2ºC: 3.51
Refrigerant: R290
Charge (kg): 1.8
Sound Pressure 1(m) 51dBA
Water Connection (Inch): 1 1/4" G
Water Flow Volume (m³/h): 3.4
Pump Pressure (m/H₂O): 7.5
Gross Weight: 232 kg
Net Weight: 198 kg
