Safety Relief Expansion Valves DSV531760
Caleffi 531 Series Safety Valve 32mm x 40mm 600kPa
Product Information
Description
Safety relief valve for domestic water systems
32mm x 40mm outlet
600kPa
Female connections
Discharge overpressure 20%
Closing differential 20%
Medium: water
Temperature range: 5–95°C
DSV531760
Caleffi
Safety Relief Expansion Valves
32/40mm
Technical Information
32mm inlet 40mm Outlet, 600kPa
Housing: Brass EN 12165 CW617N
Top part: Brass EN 12165 CW617N
Control spindle: Brass EN 12164 CW614N
Spindle seal: EPDM
Diaphragm: EPDM
Spring: Steel EN 12270-1
Knob: ABS
Operating medium: Water
Rated pressure: PN 10
Working temperature range: 5–110°C
