The Ritter Air Universal fan coil units are designed to easily blend into different interior styles and are a dual-purpose design, allowing for wall-mounted or floor-standing installation.
Features:
– PVC plastic drip tray and a patented hollow insulation layer, effectively preventing condensation while greatly improving insulation performance
– Interchangable pipe outlets for either left or right-hand installation
– Bottom water inlet
Specs:
No. of Fans: 2
Max. Sound Power db(A): 41
Cooling Capacity Range: 2200-3384kW
Heating Capacity Range: 2450-3990kW
Air flow m³/hr: 340-680
Air flow m³/hr: 340 - 680
Cooling power kW: 2.3 - 3.6
Heating power kW: 3.3 - 5.4
Pressure drop cooling kPa: 6.5- 33.8
Pressure drop heating kPa: 5.3 - 30.8
Fan power Watts: 62
Max. Sound Power db(A): 41
Fins Spacing: 2.2mm
Fins Thickness: 0.105mm
COOLING
Entering air temperature + 27°C d.b. + 19°C w.b.
Water temperature + 7°C E.W.T. + 12°C L.W.T.
HEATING
Entering air temperature + 20°C
Water temperature + 45°C E.W.T. + 40°C L.W.T.
