Vaillant EcoTEC Boiler 60kW NG

Maximum heating flow temperature: 75ºC
Range for the heating flow temperature control 30-80ºC
Maximum permissible pressure 4.0 bar
Safety discharge of expansion relief valve 4.0 bar
Nominal water flow (ΔT = 20 K) 2.500 l/h
Approximate value for the condensate volume 6.9 l/h
Effective output range (P) at 50/30°C 12.2 … 63.5 kW
Effective output range (P) at 80/60 °C 11.0 … 58.7 kW
Maximum heat input – heating (Q max.) 60.0 kW
Minimum heat input – heating (Q min.) 11.3 kW
